The first Aquila 42 Coupe in Asia has officially arrived in Thailand. Contact Primus Marine Thailand today to arrange your private viewing of this stunning new model.



AQUILA 42 COUPE POWER CATAMARAN Specifications

Features

• An exceptional performing and seaworthy double

stepped hull shape providing first in class stability

and fuel efficiency

• Aquila Hydro Glide carbon fiber semi foiling system

providing first in class performance, comfort, and

fuel efficiency

• The perfect balance of indoor and outdoor spaces,

all in a single level living package

• Spacious interior cabins with hull side windows

offering excellent views of the water

• Expansive electric opening fiberglass sunroof

providing protection from sun and weather (option)

• C-Zone digital switching system for DC powered

components

• Ability to choose between Mercury outboard

power or Volvo Penta diesel propulsion

• Easy access on and off from docks with standard

port and starboard opening cockpit doors

Interior Layout

• Single level deck plan with large cabins in each

hull

• Master cabin in port hull with VIP cabin in

starboard hull - each with walk in shower, vanity

area, and fresh water flush toilet

• Salon area with L-shaped seating to port with

fixed table that can convert to bed with fill in

cushion

• Large tempered glass windows offering full 360

degree views

• Sliding aft salon door providing a connection

between aft cockpit and interior when opened

• Galley area to starboard providing microwave, sink,

and storage cabinets throughout

• Carbon fiber central electric actuated hatch/door

providing access to forward bow seating

• Comfortable helm seating for two with forward

facing port side lounger adjacent to the helm

seating

Hull and Deck Features

• Double stepped hull design offering best in class

offshore handling capabilities

• Carbon fiber Aquila Hydro Glide semi-foiling

system

• Comfortable and protected bow seating that

comfortably seats up to 4 people

• Aft starboard fiberglass storage box including

trash can and Corian surface with ability to add

optional fridge

• Aft convertible sun lounger providing ability to sit

facing forward or convert to sun lounger with

storage below

• Designated area for optional electric BBQ

• Stainless steel railings and handholds in AIS316

• Opening port lights installed in hull side windows

• PVC rub rail with 316 stainless steel insert offering

all round protection

• Windscreen in tempered glass with variable speed

windscreen wiper

• Bow deck hatches allowing access to anchor

chain area and windlass

• Deck fill plates in 316 stainless steel - 1x water - 2x

fuel - 2 x waste

• Stainless steel mooring cleats thru bolted (10 Total)

• Well placed ergonomic handrails in 316 stainless

ensuring secure movement onboard

• LED navigation lights, running lights and anchoring

light

• Custom stainless steel retractable swim ladder

with teak steps at aft deck swim platform

• Aft cockpit and bow area all self draining

• Aft cockpit with three panel sliding door

• Optional synthetic marine decking throughout all

main level exterior and interior deck space

• Mechanical room/diesel engine access through

large deck hatches

• LED courtesy lighting located throughout

• Easy lift gas shocks for all large hatches

Aft Deck and Cockpit

• Multiple panel sliding door lockable from interior

and exterior - entrance to salon

• Sun lounger with convertible back rest and

storage inside

• Forward facing seating to port

• Fiberglass aft storage to starboard with pull out

trash can and optional fridge

• Flip down/up fiberglass engine well covers

• Mechanical/diesel engine room access from deck

hatches

• Marine waterproof 7.7” Fusion speakers (2)

• Port and starboard side boarding gates with robust

stainless steel hinge and fittings

• LED courtesy lighting

• Overhead LED lighting

• Starboard side storage aft of sliding door with

optional BBQ and fridge/freezer

• Integrated side deck steps providing easy access

to raised side decks

• Stainless steel gates (2) at center and starboard

side

• Optional retractable canvas sunshade system

with canvas material

• Self draining cockpit area

• Shore power inlet supply outlets

• Slide out stainless steel swim ladder with teak

steps

• Fresh water pull out shower (hot/cold)



Mooring System

• Electric windlass (12v-1000W) with hard wired

handheld control at anchor locker

• Polished stainless steel 35lbs anchor with rope

(200ft), galvanized anchor chain (30ft)

• Mooring kit - 6 x fenders and 6 x mooring lines

Forward Bow Seating

• Central electric walkthrough opening hatch/door

manufactured in carbon fiber materials to increase

strength and reduce weight providing access to

bow seating

• Forward facing sun lounger seating with head

rests and flip down arm rests

• Cup holders (8)

• Concealed storage areas to outboard sides for cell

phone and cup holders

• Integrated LED courtesy lighting

• Storage under removable cushions at each sun

lounger

• Marine waterproof speakers 7.7” (2)

• Stainless steel handrails

• Optional synthetic marine decking

• Central hatch for access to windlass/anchoring

system

• Port and starboard side wet locker storage for

fenders and mooring lines

Interior Helm Console / Seating

• Comfortable carbon fiber helm seating including

flip up bolsters and electric seat sliders

• Cup holders (2)

• AC vents for direct air flow (aircon optional)

• Black acrylic helm panel with flush mount

electronics installation

• Wireless phone charger (1)

• Stainless steel hand hold

• Recessed foot rests

• Manual slide opening window next to helm

• Variable position steering wheel offering multiple

function use controls at your finger tips

• Magnetic handheld compass

• USB and USB-C outlets

• Port side forward facing lounger seating adjacent

to helm seating

• Windshield wiper system connected to fresh

water supply with control at helm

• Ergonomically positioned throttle and joystick

controls

Salon / Galley

• Manual blinds for port and starboard side

windows

• Laminate finished cabinetry with solid wood

capping throughout with accented wall and ceiling

coverings

• Manual hi/low table with fold out sections - can

convert to sleeping area with fill in cushion

• Multi-Zone sound system with Fusion head unit

and 4 x flush mounted 7.7” speakers

• Upholstered panel ceilings with decorative LED

accent lighting

• Comfortable L-shaped seating to port

• Storage locker under floor in galley/salon area

• Optional expansive electric sunroof

• Designated drop down TV system from ceiling

(option)

• Carbon monoxide alarm

AC power sockets under seating

• Galley area to port side including:

• Corian work surface

• 130L/4.5 cu. ft. fridge/freezer

• 30L/1.1 cu. ft. microwave

• Storage drawers and cabinets throughout

• Wash basin with stainless steel faucet

• AC power outlets

• Integrated stainless steel handrails under Corian

countertops

• Optional synthetic marine decking

Owner and VIP Guest Cabin

(owner cabin on port side)

• Large hull side window providing natural light into

cabin with manual operated blinds

• Laminate finished cabinetry with solid wood capping

throughout with accented wall and ceiling

coverings

• Private access door to each cabin for privacy

• Aircon vents with aircon display/controller (option)

• Opening ventilation hatch in ceiling with concealed

manual blind

• LED reading lights (2)

• LED overhead ceiling lights

• Storage shelves, lockers and drawers with additional

storage under cabin mattress

• Memory foam mattress

• Cabin mattress size: Master cabin: 76” x 60”

(194cm x 153cm) VIP guest cabin:76” x 60” (194cm

x 153cm)

• USB charging ports

• Synthetic wear resistant flooring offering

maintenance free natural look

• Upholstered panel ceilings with decorative LED

accent lighting

• Carbon monoxide alarm in each cabin

• AC power sockets (2)

• Large hanging locker with storage

• Separate bathroom/shower area including:

• Hull side window with blind

• Opening portlight window for ventilation

• Bathroom vanity with sink and faucet

• GFCI protected outlets

• Toothbrush and towel holders

• Corian countertop

• Fresh water electric flushing toilet

• Walk in shower with door and port light

opening window

• Mirror

Mechanical / Diesel Engine Rooms

(diesel engines optional)

• Automatic fire suppression heat activated system

with alarm monitors at helm station

• Engine fuel system filters

• LED lighting

• Thru hulls with strainers for water supply to

primary equipment

• Automatic bilge pump in each engine room

• Excellent all around engine and systems access

for ease of maintenance

• Additional storage for storing water toys and water

sports equipment

Electrical System

• C-Zone DC digital switching system

• Inverter/battery charger Mastervolt 200A/3500W

• Master control panel for 12v and shore power service

• Dedicated engine battery chargers

• Remote battery master switches at panel

• Engine parallel control remote switch

• Dedicated engine start batteries (2 x AGM)

• House batteries = 2 x 230 A/h AGM

• 30A shore power supply inlets (2)

• Galvanic Isolator protection system

Fuel System

• Fully independent Heavy Gauge aluminum tanks

totaling 1552 Liter/410 US G with gauge at helm

station

• Manual fuel shut off valves

• Fuel tank vents

• Natural ventilation of locker

• Water and air tight bulkhead separating cabin area

• Fuel filters



Water and Bilge System

• Automatic 12v Fresh Water Pump

• Water heater (1) @ 40L/10.5Gal (only operable from

shore power and/or optional generator)

• 1 x 200 Liter/52 US G fresh water tank

• Transom pull out shower mixer (hot/cold)

• Automatic 12v bilge pumps (6)

Waste System

• Automatic grey water pump connected to each

shower drain for direct overboard discharge

• 2 x 80L/21Gal black water tanks with sea

discharge pumps and dockside pump out

• Black and fresh water levels visible through

C-Zone system

Please contact Howard Prime at +66 (0) 86 277 3360
