RCD Status: The yacht conforms with the essential safety requirements of Directive 94/25EC or RCDII (2013/53/EU as appropriate (Recreational Craft Directive) and is categorised A – “Ocean”

Hull, Deck & Superstructure Construction:

• Carbon Core-cell Epoxy thermos-formed foam sandwich core hull construction (Clear).
• Carbon Epoxy foam sandwich superstructure construction (white).
• Carbon Epoxy foam sandwich deck construction (non-skid white).

Engine & Gearboxes:

• 2 x Yanmar 4JH80; 2 x 58.8kW @ 3,200rpm.
• 2 x SD 60 SAILDRIVE transmissions.

Maintenance & Performance:

• 9 knots @ cruising speed; 1,200nm @ cruising speed.
• 12 knots @ maximum speed.
• 15 l/h @ cruising speed (TBC at 9 knots, at 7 knots with 1 x engine, around 4L/H).

Voltage Systems:

• 12, 24 & 220V circuits.

Battery Banks:

• 4 x 180A/h Mastervolt lithium batteries.
• 2 x Engine start batteries.
• 2 x Generator start batteries.

Battery Chargers:

• Mastervolt charger.

Generator:

• 2 x Fischer Panda 15000 I Performance generator.

Shore Power:

• 2 x Mastervolt shore power.

Other Electrical:

• 3 x Mastervolt Mass Combi Ultra 24/3500-100 inverter.

Fresh Water & Water Heating System:

• 2 x Pumps for water pressure; shower pumps same as water pressure.
• 2 x 50L Isotemp basic boiler.

Watermaker:

• 2 x Tecnicomar Sailor C 600 watermaker (110L/h).

Bilge Pumps:

• 6 x Bilge pumps.

Fuel:

• Total fuel capacity of 750 litres (2 x 375 l).

Fresh Water:

• Total water capacity of 600 litres (2 x 300 l).

Grey/Blackwater Holding Tanks:

• 4 x Grey water Sumo boxes 50l/m.
• 2 x Black water 150L tanks.

• B&G instruments.
• B&G sounder.
• B&G self-steering.
• Computer.
• Iridium phone.
• VHF radio.
• AIS Class B.
• B&G GPS.
• B&G chart plotter.
• B&G radar.
• Up Side Up syst. installed; but needs updating to new version/model.

Galley:

• 2 x Vitrifrigo BT series refrigerators.
• 2 x Vitrifrigo BT series deep freezers.
• Cooker-oven.
• 2 x Dishwasher.
• Washing machine.
• Air Conditioning.
• Ice maker.
• Wine cooler.

Heads/Showers:

• 4 x Electric WCs; with showers (3 guests, 1 crew).

 Heating & Ventilation:

• 5 x Dometic 6K BTU in cabins; 2 x Dometic 27K BTU in saloon.

Entertainment:

• Recessed 32’ flat screen in the saloon; motor for lifting mechanism needs replacing.
• Fusion sound system.

Summary of Accommodation:

• Spacious and clear for up to 6 guests and 2 crew in total comfort.
• Guests: 2 x king size berths (master & starboard aft) & 1 x double.
• Port hull: Owner’s stateroom with double berth king size & sofa/bed (small 1-person settee – no sofa bed).
• Starboard hull: 2 x guest cabins.
• Crew: 1 x upper & lower berth cabin.
• Lewmar flush hatches with privacy screens.
• Lewmar 10: 1 x per head, with privacy screens & 2 x in master cabin corridor.
• Lewmar 44: 1 x per stateroom, with privacy screens.
• Lewmar 4 x opening port lights 1 x per head, 2 x in master corridor & 1 x in guest cabin.
• 2 x GOIOT CE certified escape hatches.

Description of layout:

Saloon:

• 360° panoramic view.
• Galley aft to starboard.
• Dining table and U sofa up front to port.
• Chart table up front to starboard.

Chart Table:

• Up front on starboard side of the saloon, with a island counter, with storage and counter top for nav. station.

Rig:

• Southern Spars high modulus mast.
• Southern Spars high modulus boom.
• Standing rigging custom aramid & carbon.
• 1 x Custom aramid forestay with furler for Solent.
• Custom aramid lower & cap shrouds with loops to chain plates.
• Custom carbon superior & inferior diamond with integral turnbuckles.
• Custom carbon martingales with loops to chain plates.
• Reacher torsional stay A5 on textile cable.
• Dyneema running rigging.
• Halyard control lines led to forward pit.
• Sail control lines led to forward pit.
• Tack, cunningham and reef lines run to forward pit.
• Halyards and control lines equipped with lashing ends.
• All shrouds, headstay, whisker/side stays, tramps, loops for shrouds, martingale replaced with K49, 2021.
• Jib furler.
• Staysail furler.
• Code 0 Solent, staysail, reacher & gennaker furler.
• Furling lines lead to forward pit.
• Furler lines continuous, for: J0 & A5.
• Solent furler line.
• Spinlock jammers or constrictor clutches for control lines.
• Harken floating 75 mast base blocks, on loops.
• Loops or shackles for all blocks.
• Harkent staysail and Solent/Jib.
• Solent sheets run to aft cockpit by helms.
• Staysail sheets run to aft cockpit.
• Reacher & spinnaker sheet system consists of 2 x Harken snatch blocks & 2 x padeyes.
• Reacher sheets.
• Asymmetric sheets.
• Mainsheet Magic trim.
• Main halyard 1:1 new halyard in 2021 - locking headboard car by harken – 2021.
• Staysail halyard 2:1 - with 3:1 downhaul on tack.
• Reacher - asymmetric halyard 1:1 on Hall lock. Tack on 3:1. A4 on 14mm Halyard, 1:1 with Karver lock at mast base and a Tylaska on a strop at the end of the longeron.

Winches:

• Harken self-tailing winches.
• 2 x 990s electric 24V with toe controls, for all lines in forward pit.
• 4 x Lewmar 80 electric 24V with toes controls in aft cockpit (2 x helms & 2 x by davits).
• Winch kill switches for all winches.
• 2 x 10" aluminium winch handles with holders.

Sails:

• Complete Evolution set of sails from 2021.
• Mainsail 3Di square top.
• J2 3Di.
• J3 furling Solent 3Di.
• J4 3Di.
• Staysail.
• Asymmetrical Spinnaker A3.
• Code 0.
• Upwind Sail Area: 216m²
• Downwind: 460m².

General:

• Passarelle with stanchions.
• Swimming ladder.

Anchoring & Mooring Equipment:

• Lewmar V4 - V5 deck unit windlass for 100m of 12mm chain galvanized, stud linked, Rocna 55kg anchor.

Covers, Canvas & Cushions:

• Nice aft cockpit with shelter.
• Cockpit table on starboard with L sofa.
• Sofa aft facing up front.
• Sofa to port.

Tender & Outboard:

• RIB – HH.
• Yamaha 50hp outboard.

• Forward trampolines with Spectra border line, composite stanchions (1m) with three levels of Dyneema lifelines.
• 2 x Liferafts.
• 10 x Life jackets.
• 2 x EPIRBs.

• Replaced main engines: Marlin Marine.
• Replaced sail drives: Marlin Marine.
• Full tender engine outboard service/drive replacement: Marlin Marine.
• Serviced dinghy lift motors: Marlin Marine.
• Installed yd42 panel to interface new engines with B&G: Marlin Marine.
• Fischer Panda genset service: Marlin Marine.
• Brunton prop service: Yacht Engineering Services.
• Refurbished emergency hatches: Yacht Engineering Services.
• Removed, refurbished, rebuilt or replaced old hatches: Yacht Engineering Services.
• Remove/refurbish/remount escape hatches: Yacht Engineering Services.
• Steering system check: Yacht Engineering Services.
• Refurbish and replace helm steering bearings: Yacht Engineering Services.
• Sealed fuel tanks - new gaskets and fasteners: Yacht Engineering Services.
• Sealed forward tanks - new gaskets and fasteners: Yacht Engineering Services.
• Resealed black water tanks - new gaskets and fasteners: Yacht Engineering Services.
• Refurbished portlights: Yacht Engineering Services.
• New Sikaflex profiles on windows and helm: Yacht Engineering Services.
• New engine starter batteries.
• Full respray - repair & match weave, clearcoat, topsides, antifouling: Decabo.
• Full sail service and repair: Evolution Sails.
• Repaired and repainted cabin doors and frames: Snip/yes.
• Serviced hydraulic pump: At Hydraulics.
• All safety equipment serviced and recertified: Oscar Sierra.
• Streamlined winch control boxes: Eye.
• Replaced 2 x torsion cables: Rigging Projects.
• Replaced running rigging as necessary: Rigging Projects.
• Serviced locking main head car: Rigging Projects.
• Reinforced stanchion bases: Palma composites.
• New carbon clearcoat helm panels: Palma composites.
• Fill obsolete solar boxes and make covers for coach roof: Palma composites.
• Reinforced davits: Palma composites.
• Health check VHF/AIS: Tallamar.
• Installed new exterior engine throttles: Tallamar.
• Optimized Mastervolt system: Tallamar.
• Optimized C-zone: Tallamar.
• Health check autopilot computers: Tallamar.
• Reset all tank settings on C-zone to reflect actual: Tallamar.
• Replaced 4 x underwater lights: Tallamar.
• Checked power systems, including lithium batteries: Tallamar.
• Optimized B&G: Tallamar.
• Upgraded generator charging system: Tallamar.
• 14 x New solar panels, wiring, and mppts: Tallamar.
• Replaced 4 x winch buttons with two on spare.
• Serviced winches.
• Dismounted, cleaned, and serviced deck hardware.
• Replaced daggerboard organizers.
• Exterior mesh covers for side windows: Universal Nautic.
• New hard salon headliners: Universal Nautic.
• New interior upholstery: Universal Nautic.
• New exterior upholstery: Universal Nautic.
• Complete fender set and replace covers.
• Refurbished and replaced Jeffa rudder bearing parts.
• Replaced any broken bilge cover latches.
• Cleaned and descaled plumbing.
• Checked and replaced door handles as necessary.
• Re-bead Sikaflex behind sink galley.
• Refurbished and replaced as necessary hatch blinds.
• Replaced broken Oceanair blinds.
• Power socked check: Eye.
• Inspected & serviced fridge and freezer compressors/aircons: Titan.
• Added anchor chain to bring to 100 meters: Extreme Marine.
• Cleaned all tanks and water system with certification: Ocifar.
• Installed second watermaker, both serviced.
• Cleaned cooling fans and filters.
• Replaced any faulty cupboard and drawer latches.
• Refurbished teak shower floor grates.
• Flushed and cleaned all ac drain hoses.
• New furling staysail: Evolution Sails.
• Rig pull and service, including Upgrading Mast Base Plate.

New standing rigging.
